Kia Cee'd: Interior features / Cargo security screen (wagon)

Use the cargo security screen to hide items stored in the cargo area.

To remove the barrier net
1. Loosen the straps by using the strap adjusters and remove the strap hooks from the hook holders. 2. Remove the net upper shaft by pulling it through the large holes. 3. Remove the barrier n ...

To use the cargo security screen
1. Pull the cargo security screen towards the rear of the vehicle by the handle (1). 2. Insert the guide pin into the guide (2). ✽ NOTICE Pull out the cargo security screen with the handl ...
